Products

Precision Machining

Our complete CNC precision machining center, in combination with our years of experience in this field, can provide you and your company with parts machined in both conventional and exotic alloys.

Screw Machining

Screw machining, or production machining, refers to the process of using automatic, multiple-spindle machines to produce threaded parts in mass quantities. Screw machining is considered the fastest and most cost-effective way to produce large quantities of threaded parts.

Stampings

Need Info

Wire EDM

Wire EDM is a process whereby a wire, typically .006 inch to .008 inch in diameter, is electrically charged at a very high voltage and used to cut precision shapes in prismatic components. The wire is passes from one spool to another and is guided by and an upper and lower guide as it cuts. There are numerous advantages to wire EDM machining such as the ability to cut very precisely, cut nearly square internal corners and cut tapers that would be virtually impossible to cut otherwise.

Laser Welding

When a laser’s concentrated energy is used for welding it gives many advantages over conventional resistance methods. The technology is already spreading through the automotive industries of America and Europe. The process is a non-contact one that directs laser outputs of 2-10 kW into a very small area. This means that power levels in excess of 103-105Wmm-2 are produced on the surface of the parts to be welded. The laser beam makes a ‘keyhole’ and the liquid steel solidifies behind the traversing beam, leaving a very narrow weld and heat affected zone (HAZ). The weld is approximately 1 mm wide and the surrounding material is not distorted. Because the weld bead is small, there is usually no need for finishing or re-working and this reduces costs. In the case of zinc-coated steels, the narrow weld also means that it is protected by the sacrificial galvanic corrosion in the adjacent zinc layers. As access for welding is required from one side only, many different joint configurations are possible that were previously unavailable. And so laser welding opens doors to innovative joint designs.

Plasma and Water Cutting
